MF55 Series Thin Film Temperature Measurement NTC Thermistor
| Item No : | MF55 |
| Resistance Value : | 5K-500 kΩ |
| Resistance Tolerance : | ±1%, ±2%, ±3%, ±5% |
| B Value 25/50 (K) : | 3270K~4750 K |
| Temperature Range : | -40~+125 °C |
| Thermal Dissipation Coefficient : |
≥0.8 mW/°C |
| Thermal Time Constant : | ≤5 s |
| Maximum Rated Power : | ≤50 mW |
PRODUCT INTRODUCTION
Product Description
The MF55 series has high sensitivity, fast thermal response, good stability, and high reliability. The surface is packaged with thin film.
Product Features
1.Application scope:
- Suitable for computers, printers, and household appliances.
2. Features:
- High sensitivity and fast thermal response.
- Good stability and high reliability.
- Good insulation and high resistance accuracy.
- Safe to use, small in size, lightweight, sturdy in structure, and easy to automate installation.
